Fire Pump Tohatsu
Type : V20D2S, VC82ASE, V72AS, VC85BS
More attractive features and functions are added to maximize efficiency of fire services.
1. Light weight and compact
Engine and pump castings are made of anti-corrosive aluminum-alloy to reduce weight and prolong
working life. Compact unit in its class fits existing locker space, also can be carried by 2 firemen.
2. High pump performance
Both engine and pump are designed and developed specifically for fire-pump application by Tohatsu,
ensuring higher pump performance for its class.
3. Reliable engine with optimal engine start-up
The engine of VC82ASE is originally designed by Tohatsu for this model. Equipped with oil pump,
gasoline and engine oil are mixed automatically at a precise ratio to engine speed without mixing fuel
and oil by operator.
4. Priming
Quick priming is provided by operating Rotary Vane Vacuum Pump.
Prime 1meter in 4seconds ( 6m suction hose)
Prime 3meter in 5.5seconds ( 6m suction hose)
Prime 6meter in 8.0seconds ( 6m suction hose) .
5. Centralized control
All gauges, throttle dial, control switches, and other warning lamps are grouped on the control panel
for easy operation.
6. Cooling water recirculation system
Engine cooling water is returned to the pump eliminating discharge outside of the pump, and making
surrounding area soaked.
7. Unique auto choke carburetor
This device helps engine start easier in all seasonal temperature conditions.
8. Engine overheat protection sensor
Overheat protection is provided on this model to safeguard the engine from cooling water loss,and to
protect engine when water is not discharging.This device stops the engine automatically when engine
temperature reaches 80 . Reset switch is provided to release the sensor after it stops the engine.
Accessories
1. Battery charger
2. Floodlight projector
3. Plastic toolbox
Adapters:
Some different type of adapters for suction port and discharge ports are available.
